Advanced Refuelling
for an Evolving Industry
With a new era of energy comes increased demand for better industrial technology.
Using innovative engineering, Energera's Frac Shack™ and NG SideKick™ makes utilizing field gas and refuelling safer, cleaner, and more efficient. Entirely self-contained and self-sufficient, each unit seamlessly integrates into existing systems for fast and simple transitions.
Book a Demo
Automated Frac Fuelling
Frac Shack™ solutions are transitioning the industry from pure diesel spreads to natural gas and bi-fuel spreads. Trusted by some of the most prolific producers, Frac Shack's technology is the go-to auto fuelling solution that can support bi-fuel frac fleets operating in some of the most challenging basins in the world.
Eliminate the risks, stress, and nonproductive time in the hot zone with our patented automated fuelling technology.
Utilizing Energera's Frac Shack equipment allows for the transition to natural gas, saving operators millions of dollars in fuel costs on every job.
Learn More
The Frac Shack™ Advantage
Safe
Efficient
Cost-Effective
Frac Shack™ automated fuelling systems significantly reduce the health and safety risks to people and the environment, featuring an innovative design that eliminates the risk of fuel spray while easily adapting to any existing equipment—saving your team time, money and effort.
Integrated Technology Solutions
Drilling & Completions
Integrated Technology Solutions
Drilling & Completions
The Diesel-Only FracFueler™ operates up to 28 diesel lines. Always depressurized. Always on the fly. Always Frac Safe.
Specifications
FracFueller-12
FracFueller-20
FracFueller-24
FracFueller-28
Diesel Lines
12
20
24
28
Trailer Length
53'
53'
53'
53'
Storage
7,900 gallon tank (30,000L)
7,900 gallon tank (30,000L)
7,900 gallon tank (30,000L)
No onboard storage. Ties into larger storage.
FracFueller-12
12 diesel lines
53' trailer
7,900 gallon storage tank (30,000L)
FracFueller-20
20 diesel lines
53' trailer
7,900 gallon storage tank (30,000L)
FracFueller-24
24 diesel lines
53' trailer
7,900 gallon storage tank (30,000L)
FracFueller-28
28 diesel lines
53' trailer
No onboard storage. Ties into larger storage.
Integrated Technology Solutions
Drilling & Completions
The Bi-Fuel FracFueler™ operates up to 20 natural gas lines & 26 Diesel Lines. Subup for a cheaper, cleaner fuel.
Specifications
Bi-Fuel FracFueler-14
Bi-Fuel FracFueler-20
Diesel Lines
14
26
Natural Gas Lines
14
20
Gas Source Temperature (c/F)
10 – 60c / 50 – 140F
10 – 70c / 50 – 158F
Gas Source Pressure (psi)
50 – 210
50 – 230
Maximum Flow Rate
13,750 scf/h per line
165,000 scf/h total system capacity
13,750 scf/h per line
275,000 scf/h total system capacity
Trailer Length
53'
53'
Storage
7,900 gallon tank (30,000L)
No onboard storage
Bi-Fuel FracFueler-14
14 diesel lines
14 natural gas lines
10 – 60c / 50 – 140F
gas source temperature
50 – 210
gas source pressure (psi)
13,750 scf/h per line
165,000 scf/h total system capacity
53' trailer
7,900 gallon storage tank (30,000L)
Bi-Fuel FracFueler-20
26 diesel lines
20 natural gas lines
10 – 70c / 50 – 158F
gas source temperature
50 – 230
gas source pressure (psi)
13,750 scf/h per line
275,000 scf/h total system capacity
53' trailer
No onboard storage
Integrated Technology Solutions
Drilling & Completions
The NG SideKick is the Cheapest & Cleanest way to frac. Pair the SideKick with a Bi-Fuel FracFueler & use your own gas to power bi-fuel & electric fracs. On its own, the SideKick™ is perfectly suited for natural gas power on drilling operations.
Specifications
NG SideKick
(Bi-Fuel Spreads)
SideKick Solo
(Bi-Fuel Spreads & Rigs)
Super SideKick
(Electric Spreads)
Inlet Size
2” 600# RF
2” 600# RF
3” 1500# RF
Max Pressure at Inlet
1,400 PSI
1,400 PSI
1,400 PSI
Low Pressure Outlet Size
3” 150# RF
3” 300# RF
4”300# RF
Low Pressure Outlet Pressure
275 PSI
740 PSI
740 PSI
High Pressure Outlet Size
N/A
N/A
3” 600# RF
High Pressure Outlet Pressure
N/A
N/A
1,346 PSI
Gas Volume Throughput
5.5mmscfd (1000 PSI Inlet Pressure)
3.22 mmscfd (1000 PSI Inlet Pressure)
8.5 mmscfd (1300 PSI Inlet Pressure)
Vessel PSV Set Point
275 PSI
1,440 PSI
1,346 PSI
Liquid Dump Valve Capacity
647 BPD @ 275 PSI
647 BPD @ 275 PSI
1457 BPD @ 1300 PSI
Liquid Storage Capacity
500 Gallons
500 Gallons
500 Gallons
Skid Footprint
8’ x 23’
8’ x 25’
8’ x 28’
1 hr. Contingency Compresser
No
No
Yes
NG SideKick
(Bi-Fuel Spreads)
2” 600# RF inlet size
1,400 PSI Max Pressure at Inlet
3” 150# RF Low Pressure Outlet Size
275 PSI
Low Pressure Outlet Pressure
High Pressure Outlet Size: N/A
High Pressure Outlet Pressure: N/A
5.5mmscfd (1000 PSI Inlet Pressure)
Gas Volume Throughput
275 PSI Vessel PSV Set Point
647 BPD @ 275 PSI
Liquid Dump Valve Capacity
500 Gallons Liquid Storage Capacity
8’ x 23’ Skid Footprint
1 hr. Contingency Compresser: No
SideKick Solo
(Bi-Fuel Spreads & Rigs)
2” 600# RF inlet size
1,400 PSI Max Pressure at Inlet
3” 300# RF Low Pressure Outlet Size
740 PSI
Low Pressure Outlet Pressure
High Pressure Outlet Size: N/A
High Pressure Outlet Pressure: N/A
3.22 mmscfd (1000 PSI Inlet Pressure)
Gas Volume Throughput
1,440 PSI Vessel PSV Set Point
647 BPD @ 275 PSI
Liquid Dump Valve Capacity
500 Gallons Liquid Storage Capacity
8’ x 25’ Skid Footprint
1 hr. Contingency Compresser: No
Super SideKick
(Electric Spreads)
3” 1500# RF inlet size
1,400 PSI Max Pressure at Inlet
4”300# RF Low Pressure Outlet Size
740 PSI
Low Pressure Outlet Pressure
High Pressure Outlet Size: 3” 600# RF
1,346 PSI
High Pressure Outlet Pressure
8.5 mmscfd (1300 PSI Inlet Pressure)
Gas Volume Throughput
1,346 PSI Vessel PSV Set Point
1457 BPD @ 275 PSI
Liquid Dump Valve Capacity
500 Gallons Liquid Storage Capacity
8’ x 28’ Skid Footprint
1 hr. Contingency Compresser: Yes
Why Choose
- Entirely self-contained unit with accompanying generator
- Remote fuel tank monitoring
- Metered fuel consumption information by well and stage
- Options for manual or automatic operation
- No pressurized fuel lines
- Trailer-mounted units for easy transport
- Bi-fuel options available
- No retrofitting required for existing pumper equipment
- No slowing or stopping to refuel any equipment on site
Advantages of Bi-Fuel Spreads
Frac Shack™, powered by Energera, has developed the industry's first combined diesel and natural gas distribution unit for hydraulic fracturing spreads. We'll help you transition so you can enjoy the following benefits:
Lower Emissions
Natural gas and bi-fuel spreads burn cleaner than a diesel fuel delivery system. With the addition of Frac Shack's enhanced safety and efficiency features, you'll be lowering your environmental footprint throughout the whole hot fuelling process.
Money Saved
You'll save more on fuel when you make the switch away from diesel. Transitioning to natural gas could save you up to $2 million per pad.
Learn More
Our Mission
Smarter
Greener
Safer
Cleaner
Energera is dedicated to helping the energy industry transition to cleaner, safer and more sustainable practices. Our patented technology enables companies to reduce their ecological footprint while optimizing their operations, ensuring we can all reach ambitious goals
